Sharpening Part 20 – Flattening and Polishing the Ura

A mind needs books as a sword needs a whetstone, if it is to keep its edge.

George R.R. Martin

Now that we are geared-up and our sharpening stones are flat, let’s make our blade sharp. The first step in sharpening a new blade is truing the ura. So let’s get to it.

General

All standard chisel blades and plane blades, whether Japanese or Western, need to have a planar flat or ura that it will be in contact with the sharpening stones its full width, and ideally, full length. Perfection is not necessary, however, so don’t let yourself get obsessive. If the ura is arched (concave), for instance, so it is in contact with a flat sharpening stone near the neck of a chisel, or head of a plane blade, and the cutting edge, that may be workable, but it must be in complete contact right behind the cutting edge. I cannot stress this importance of this point too strongly.

Once the ura of your chisel is flat and true, you should not need to true it again unless the blade needs major repairs. Japanese plane blades, on the other hand, are a little more complicated because repeated sharpenings tend to gradually wear out the land right in front of the cutting edge, called the “ito ura,” and the bevel must be tapped-out to compensate, and the ura re-flattened. I won’t delve into the subject of “tapping out” the ura of plane blades in this post but will save it for future discussions about Japanese planes.

Evaluate the Ura

The first step in flattening or truing an ura is to evaluate its condition. Don’t start grinding away willy nilly without first checking it and making a plan. If you find you cannot stop yourself, don’t walk but run to the nearest pharmacy and buy a bucket of the medicine discussed in part 19 in this series about maintaining sharpening stones.

There are several ways to check the ura’s condition. A narrow straightedge works well in most cases. Place the edge on top of the full length of the shiny land at one side of the ura all the way to the cutting edge. Keep the straightedge touching the land; Don’t let it span the hollow- ground urasuki. Hold the straightedge and blade up to a strong light source and look for light passing between them. This technique is quick and dirty and will suffice in most cases, but does not tell you a lot about twist.

Use a straightedge to check the right and left lands for flatness. It doesn’t do any good to span the hollow-ground urasuki, so don’t bother. These photos are taken from above for clarity, but you want to hold the blade and straightedge together up to a strong light to observe any light showing between them that will indicate a gap. I am using a small square, but a simple small straightedge is more convenient. This takes a bit of coordination so be careful not to drop a chisel on your toe. I’ve done this once or twice before. Monkey-football.
This is a 30mm Sukemaru atsunomi, a famous brand and an excellent and powerful chisel hand-forged by Mr. Usui from Shirogami No.1 Steel. It’s in pretty good shape, but can benefit from a little truing as can most new chisels and plane blades.

Another method to check the ura for planar is to paint the shiny lands with dark marking pen ink or Dykem liquid, apply a bit of fine sharpening stone mud to a piece of flat glass, like the piece mentioned in Part 17, and rub the blade’s flat or ura over the glass. The high spots will become obvious. If the ura is banana shaped (convex), mark the high spot with your marking pen. More often than not, the ura of chisels will be generally flat, but the last 6mm or so of the cutting edge will be curved upwards towards the chisel’s face.

I learned two things from my examination of this Sukemaru brand atsunomi. First, there is a high spot (convex) at the skinny land on one side located approximately 1/2 to 5/8 the blades’s distance from the cutting edge. The land on the other side seems a little low. Hmm, curious. This is a bit unusual, but it happens when a blade warps during heat treat, which Shirogami steels tends to do frequently.

The second problem I observed was that the last 3~4mm of the land right behind the cutting edge curves downward away from the ura just a tiny bit, enough to cause problems.

I next need a plan to resolve these problems with a minimum of time and effort and without making things worse.

Make a Plan

The temptation to start grinding away immediately will be powerful. If it becomes too much, take a coffee cup or three of the medicine mentioned above and slather it on your head forcefully. Don’t hold back, for Pete’s sake, rub it in really good now. Some say my excessive use of this medicine is why I am as bald as an egg, but I prefer to believe it is caused by the light radiating from my gigantic brain (ツ). Thank goodness for my aluminum foil skull cap with its protruding copper wires!

Any plan needs goals and objectives. In this case the goal is a perfectly planar ura, but if this goal is difficult to achieve quickly there is an objective you should plan to achieve immediately in any case, one that may make it possible to achieve the larger goal over multiple routine sharpening sessions without any special effort.

As I keep harping, to make a chisel or plane work well, you need a flat area right at the cutting edge. This is where the cutting occurs and the area I need to keep sharp, so I will make creating this flat area the first objective in my plan, and then determine the steps to achieve it. Make certain every step in your plan and every stroke on the stones gets you closer to this objective, not further away. This means working smart.

If the blade is arched (concave), touching at two points, one near the neck of the chisel blade, or head of the plane blade, and at the other at the cutting edge, and not in between, all is well. I recommend you leave a blade like this as-is because after a few sharpening sessions the ura will become flat and twist-free without any special effort, and the blade will become very sharp and be entirely functional.

If the blade is wavy (rare) or banana-shaped (convex), your plan needs to take those details into account.

I located the highest point of the bulging area at the ura and marked a line across it with my marking pen. I then measured halfway between this line and the cutting edge and made another line. This area we will call the “focus line.” It is here where I need to focus the most pressure when grinding down the ura, not the entire length of the blade.

The purpose of doing all this prissy planning and layout work is to protect the right and left side lands from being wasted unnecessarily. Newbies try to work the entire length of the blade, but this is illogical and ignores three points. The first point is that the majority of the metal I need to waste is usually located to the right and left of the land nearest the cutting edge, not the full length of the blade, so there is little benefit to grinding the entire ura. The second point is that the side lands are thin as a blade of grass and will abrade very quickly with almost no effort. Besides, without using large plates and stones, it is very difficult to work the blade’s full length accurately without wearing notches in the side lands anyway. The third point is it makes no sense to try to grind down the land nearest the neck since the plane of the ura hinges on this land. Best to leave it alone and focus my efforts where they will make a difference.

Plane blades don’t even have a land near the head, so the futility of working the entire ura on plane blades is even more obvious than for a chisel.

Work the Plan

The traditional Japanese tool used to flatten and/or correct ura is a smooth steel lapping plate called a kanaban, meaning “metal plate.” To use it, carborundum powder and water are placed on the plate, and the blade is lapped. This is not a difficult process at all, but there is a tendency for the blade’s perimeter to be ground more than the interior areas as the grit is forced in between the kanaban and the blade’s perimeter. To avoid this tendency, and to speed the process up, I prefer to use diamond plates instead of kanaban.

Whatever plan you developed, and whichever tool you selected for this job, the time has come to work the plan. Do you need more medicine? A bigger coffee cup?

First, color the ura’s perimeter lands with a marking pen or Dykem to help you see where the ura is being ground down. Don’t ever guess.

Place the most pressure on the focus line selected above. Move the blade back and forth (not side to side) onto and off of the diamond plate or kanaban with the cutting edge and the focus line always touching the diamond plate or kanaban. Don’t go past the high point for now. Be careful to not grind a notch into the narrow side lands where they meet the edge of the diamond plate or kanaban. Most people make this mistake at first.

Grind the ura down so the line at the highest point and the cutting edge is fairly flat.

Work the blade on and off the edge of the diamond plate using short strokes and without going much past the highest point marked earlier. This works because the right and left side lands are thin and can be abraded in just a few strokes. I have moved my fingers to reveal the lines, but in actuality my fingers will press down hard on the focus line while working the blade.
Using a stick to apply more pressure to the blade. I am holding the end of the stick and the chisel’s handle together in my right hand. This is simply illustrating a technique. This chisel did not actually require this sort of aggressive attention.
The same stick technique works even better for plane blades and makes it easier to apply pressure right behind the cutting edge. When doing this, however, be sure to work the blade both forward and backward while moving it right and left on and off the plate’s edge to avoid digging a trench in the narrow side lands.

Remember, the narrow lands at the sides of the hollow-ground urasuki will abrade down quickly. And the rest of the ura can be gradually flattened during subsequent sharpening sessions using regular sharpening stones. It doesn’t need to be made perfect immediately. What matters most is the steel on the land right at the cutting edge.

The high spot on the land near the top of the photo has been relieved after a few passes on the #400 diamond plate. The side lands are in fair condition, and the land behind the cutting edge (itoura) needs just a little more work.
After a few more passes on the diamond plate, the ura is in good shape. Note the land at the photo’s bottom is not in full contact, but the opposite side is. This is will not impact the blade’s performance, and will work itself out during future sharpening sessions without special attention.
Flattening my stones before using them. Notice I am using two 1,000 grit stones to save time and stones. Don’t neglect flattening your stones, whether you use waterstones, novaculite stones, coticule, or even sandpaper.
Working the ura on the flat 1000 grit waterstone. Did I mention it is flat? Notice that I am working on and off the stone, not side to side, to save the right and left lands. Some but not all strokes are full length. The goal is simply to remove the deep scratches left by the diamond plate.
The ura after polishing on the flat 1000 grit waterstone. At this point the ura is in good shape. Notice how the land at the photo’s left is wider that elsewhere. This increase in width developed because this location was the high spot on this convex ura. Notice how the land on the left side is not even touching the plane in one area. What you should take away from this photo is the realization that if I had focused my efforts on this high location first and ignored the downward curvature of the land nearest the cutting edge, I would have wasted a lot more time and valuable metal only to shorten the useful life of this excellent chisel. Do you see the benefit of carefully checking the ura’s condition, making a plan with clear goals and objectives, and then working the plan? Did the medicine work? Next, we’ll work on the bevel, make a tiny burr, polish it off by making a few strokes alternating from bevel to ura, and be ready for the finishing stone.
Working the bevel on the flat 1,000 grit waterstone. Notice the mud piling up in front of the blade indicating the extreme cutting edge is in contact with the stone. I am applying pressure only on the push stroke to prevent the stone from rocking and developing a “bulging bevel,” A honing jig is not necessary.
The bevel after working on the 1,000 grit waterstone. No jigs were used. No “tricks” involving rulers were used. A silly, inefficient “micro-bevel” was neither wanted nor needed. The bevel is perfectly flat. Flattening the ura and polishing both ura and bevel to this level took less than ten minutes. When the purchaser of this blade eventually dulls the edge, he should not need to spend more than 2~3 minutes to sharpen this blade once his gear is ready, assuming he is able to sharpen freehand.

Polish a blade’s ura up to the level of your finest finishing stone once, and don’t touch it with rougher stones again unless it is absolutely necessary, or further gradual flattening is required. This means that in normal sharpening sessions you must remove all the damage at the cutting edge by abrading the bevel with the rougher stones, and only when the bevel is ready for the finish stone, do you work on the flat or ura, alternating from bevel to flat/ura until all defects, burrs, and even visible scratches are polished away.

If you condition the flat (ura) side of the blade correctly, and keep it polished, you should not need to work it on anything but your finish stone until it is time to tap out and grind the ura or back in the case of plane blades. Therefore, the bevel side of the blade is where we spend most of our time and effort.

Now that the ura is in good shape, we will look at sharpening the other side of the wedge, the blade’s bevel, in the next post in the series.

YMHOS

Links to Other Posts in the “Sharpening” Series

Sharpening Japanese Woodworking Tools Part 1

Sharpening Part 2 – The Journey

Sharpening Part 3 – Philosophy

Sharpening Part 4 – ‘Nando and the Sword Sharpener

Sharpening Part 5 – The Sharp Edge

Sharpening Part 6 – The Mystery of Steel

Sharpening Part 7 – The Alchemy of Hard Steel 鋼

Sharpening Part 8 – Soft Iron 地金

Sharpening Part 9 – Hard Steel & Soft Iron 鍛接

Sharpening Part 10 – The Ura 浦

Sharpening Part 11 – Supernatural Bevel Angles

Sharpening Part 12 – Skewampus Blades, Curved Cutting Edges, and Monkeyshines

Sharpening Part 13 – Nitty Gritty

Sharpening Part 14 – Natural Sharpening Stones

Sharpening Part 15 – The Most Important Stone

Sharpening Part 16 – Pixie Dust

Sharpening Part 17 – Gear

Sharpening Part 18 – The Nagura Stone

Sharpening Part 19 – Maintaining Sharpening Stones

Sharpening Part 20 – Flattening and Polishing the Ura

Please share your insights and comments with everyone in the comments section below. If you have questions or would like to learn more about our tools, please use the questions form located immediately below.

Sharpening Part 17 – Gear

Do what you can, with what you have, where you are.

Theodore Roosevelt

Sharpening can be a stuff-intensive process, so I want to reduce the number of accoutrement to the barest minimum especially since portability is always a factor in my case. The following is a list of some gear, besides sharpening stones, that I am confident will prove useful whether in your workshop or the jobsite.

I will first list the gear needed for general sharpening either in the workshop or the field. At the end of this article that I have listed a minimal set of gear for use specifically in the field where space and weight might make it inconvenient to carry the heavier/bulkier general set of sharpening gear.

General Set of Sharpening Gear

The following is a list of tools and equipment I think are indispensable for sharpening Japanese woodworking tools in general and in many, but not all, circumstances. I have not included some tools that may be necessary for doing “uradashi,” i.e. “tapping out” the hollow-ground urasuki of Japanese plane blades. So here we go.

  1. Stone Base or Holder: A wooden base with a wedge to secure stones is the old standby, but repeated wetting and drying and the resulting expansion and contraction may compromise a wooden base over time. For my synthetic stones I have come to prefer the commercial bases with twin metal rods and rubber feet. They are unromantic, but are durable, stable, non-slip, grip the stone tightly without breaking it, and work well anywhere. If you decide to make and use a wooden base, I highly recommend Ipe wood because it is stable, unaffected by water, won’t rot, and bugs hate it.
Washing powder storage square plastic buckets in 2L 5L 8L 10L 15L 18L 20L

2. Soaking Bucket for stones: A medium size plastic or steel mop bucket (not the heavy industrial unit with rollers) is best for soaking stones because they are durable, and their more or less rectangular shape is superior to round buckets for leaning stones on end against the inside walls. You don’t want to stack the stones on top of each other if you can avoid it. Any durable bucket that doesn’t leak will work, but a tightly-fitting lid is a big advantage. You will need to soak all but your diamond plate and finishing stones in this bucket before use.

Related image

I soak my synthetic stones 365 days a year. I close the lid to prevent evaporation and keep out mosquitoes, journalists and tax collectors, and add either washing soda, borax or a few drops of Simple Green ProD5 concentrate to the water to prevent bugs and algae from growing when I won’t be using the stones for a while. Simple Green is a better bug/algae killer, but Borax has the advantage of making the water slightly alkali which helps prevent rust in my blades during sharpening.

Some stones use a magnesium-based binder that can dissolve and weaken them if left soaking for long periods of time. Please refer to the manufacturer’s instructions.

3. Glass Plate: 9mm~12mm thick float glass. This is used to true the faces of waterstones when they become distorted through use. The piece I use is 60mm x 30mm x 10mm. This plate can be used for many other purposes including checking the fettle of your plane’s soles. I leave this in my workshop. We will discuss how to use this in future posts in this series, God willing and the creek don’t rise.

4. Working Surface: If working outside, a Japanese craftsman will place his stone holder directly on the ground or concrete slab. A craftsman that works inside a shop will often have a wooden or plastic box with a board spanning the narrowest dimension forming a bridge. The stone rests on this bridge, often with a wet towel between board and stone to prevent slipping. This box, called a pond, catches water and mud dripping from the stones. The ideal situation is a board spanning a sink with a faucet of running water. When away from the workshop, I prefer to place a piece of fiberglass-reinforced rubber roofing membrane on a truck’s tailgate or stack of boards or gypboard at a jobsite. I can roll-up this lightweight, tough, and absolutely waterproof mat and stuff it into my toolbox for easy transport. In my workshop, I use a large plastic cutting mat on my workbench, but any waterproof non-slip surface will work. No need to get fancy. My stones and sharpening gear are stored under my workbench close at hand.

5. Water Source: While sharpening, you will frequently need water to wet your stones and rinse blades. If you work at a sink, use the faucet. If you work outside, a garden hose works great. Some people, mostly knife sharpeners who seldom use stones finer than medium grit, will scoop water from their pond or bucket to wet their stones. However, since stone slurry drips into the pond, or washes off the surface of stones soaked in the bucket, this water will always contaminate stones with the grit from rougher stones, making it difficult to remove all the scratches left by the previous stone. To avoid this contamination, always use clean water for wetting and rinsing.

Some people prefer a spray bottle to add water, but spray bottles wet things I prefer to keep dry, so a better choice, in my opinion, is a plastic bottle such as a dishwashing soap bottle or a plastic lab wash bottle with a bent tube coming out the top. Almost any plastic squeeze bottle will work.

Tap water contains chlorine in all but backward countries, and chlorine accumulates and accelerates rust, so I use distilled water in my wash bottle, and add washing soda or borax to adjust the water’s PH, a technique I learned from sword sharpeners.

Some people add just a bit of liquid lye to their water to adjust the PH. This chemical can be purchased from industrial cleaning supply companies. Too much will damage your skin, so be careful. Also good for keeping Iron Pixies in the shadows.

6. Sharpening Station and/or Sharpening Pond: I don’t use a sharpening pond, and don’t believe them to be essential, but several practical options are illustrated below.

余暇のある時や休日だけに出現するものであるにせよ、専用の研ぎ場があるというのは工作をするものにとって幸せなことです。自分なりに工夫を重ねながら研究を深めてゆくのは、何よりも楽しみを感じさせてくれるでしょう。
A bridge placed over a sink forms the ideal sharpening station. Professional workshops frequently use this classic arrangement. Flush the drain well. You may need to remove the sinks’s P trap and clean sharpening stone mud out of it every couple of years.
Plastic boxes placed inside a wooden box make a portable sharpening pond and stone storage box. There are dozens of variations on this theme possible.
Related image
Perhaps the best solution in my experience (short of a dedicated sink) is a plastic box to catch water, with another plastic box nested inside containing sharpening accoutrements such as a wash bottle, brush, abrasive powders, an oiler, and nagura stone. This equipment, along with the sharpening stones, 2 bases and stainless steel straightedge pictured, can be stored inside the box and the lid closed for ease of transport and to keep out pixie dust. This is an inexpensive and extremely practical solution, but be sure to use a high-quality box made of high-impact plastic.
Another plastic box used as a sharpening pond with a simpler bridge.
Image result for straightedge

7. Stainless steel straightedge: Use this to check stones for flatness and wind, and cutting edges for straightness. Don’t use a plain steel one unless you want to give the iron pixies skulking under your workbench great joy. The thinner the better. The thick blades used in combo squares are difficult to use in less than ideal light

8. Wiping materials: You will need something to clean and dry your blades during sharpening sessions. Rags work well for wiping and drying blades, and can be washed and reused, but be careful to avoid cross-contamination. Paper towels are most effective and convenient in my experience, but they cost money and make garbage. Decisions decisions.

The classic Japanese “Baby Turtle” brush with palm-fibre bristles.

9. Scrub brush: A clean stone is a happy stone, as are bases, buckets and glass plates, all of which have grooves and scratches and holes where grit can hide. Scrub brushes are great for digging out this contaminating grit. Palm fiber brushes are ideal because the bristles are finer and grit does not get embedded into the bristles as much as plastic brushes.

Lie-Nielson Honing Guide. An excellent if expensive tool.

10. Honing Guide: This tool is optional. I hesitate to recommend these jigs because they can easily become a crutch preventing you from becoming proficient at freehand sharpening. However, jigs make it much easier and quicker to shape blades to the desired angle on rough stones, especially when correcting a double-bevel or bulging bevel to a more useful single, flat bevel. Eclipse-style honing guides work well. The die-cast versions are inexpensive. Lie-Nielson makes a terribly expensive version machined from stainless steel that I am fond of. Jigs won’t work for all blades, but it is worth having one.

tzushimanagura8_4
A Tsushima Nagura Stone

11. Nagura Stone: More details will be included in next post in this series.

Minimal Set of Sharpening Gear

Sometimes, especially when working at remote jobsites, weight and/or space may impose physical limits on the tools we can carry with us. The following is a list of the minimal set of sharpening tools I bring in these situations.

1. Stone Base: At the jobsite the stability this tool provides becomes more critical than ever, but if an ultra-light set of tools is needed, then it can be eliminated by placing the stone directly on the rubber sheet I use as a portable working surface.

2. Soaking Container: There are many potential solutions for soaking stones in a minimalist or ultra-light situation. I will describe just a few here. If I need to able to move wet waterstones to and from the jobsite during the workday, but a bucket full of water is not convenient to haul around without a truck. If clean water is available at the jobsite (water coming from newly-installed pre-flush plumbing may not be clean, BTW, and immediately post-flush it may contain lots of chlorine used to sterilize the pipes and fittings), then the minimalist solution I employ is to use a dry plastic bucket to carry tools, including sharpening gear, to and from the jobsite. I then add water before beginning the work day. Depending on the other tools I will need during the workday, this is often a good choice. Another option is to scrounge a joint compound bucket or paint bucket and leave it at the jobsite. But unless I have a gang box or other trustworthy tool lockup available at the jobsite, I still may need to transport at least one wet sharpening stone to and from the jobsite each day. The ultra-light solution I sometimes employ is to carry my waterstone(s) in a durable plastic container with a watertight lid, such as the thinner (6cm) rectangular containers by Tupperware. Water can be added at the jobsite to keep the stone(s) soaked and ready to rock-n-roll. And with the lid closed, dirt and dust can’t get in. An even lighter option is a heavy plastic bag. I place the stone(s) in the bag and carry it in my tool bag. At the jobsite, I can add water and close the bag with a thick rubber band to soak the stone(s). But be forewarned that these bags will not protect the stones, and the stones will make holes in the bag at the worst possible time.

3. Working Surface: I use the fiberglass-reinforced rubbber roofing membrane described in item 4 above. This is invaluable for many applications.

4. Water Source: Clean water is necessary even in the field to add to the stones and to wash mud off tools. To save space, I use a small plastic squeeze bottle with a tightly closing lid that originally contained ketchup. If clean water is available at the jobsite, I carry it in my toolbag empty.

5. Stainless Steel Straightedge: See Item 7 above. I use a thin, flexible, lightweight one in the field.

6. Wiping Materials: A clean face towel and a some folded paper towels work well.

7. Scrub Brush: I always bring my “Baby Turtle” scrub brush. It’s lighter in weight than a plastic brush and comes in handy for tasks beyond sharpening too.

8. Nagura Stone: Just in case I need to get an extra-fine finish.

The selection of stones I use at the jobsite will depend on the work planned for that particular day, but the minimal set is a 400 grit diamond plate, a 1,000 grit synthetic waterstone, and a 6,000 or 8,000 grit synthetic finishing stone. If I anticipate a lot of sharpening, and if weight is not critical, I will bring two 1,000 grit stones to provide 4 flat sharpening surfaces thereby reducing the need to spend time flattening stones at work. I can also use them to flatten each other. If I need to do some fine finish planing, such as when doing door modifications/installations, I will bring a 10,000 grit synthetic waterstone. And of course I always carry a Tsushima Nagura stone.

In the next post in this romantic series of adventures in sharpening will focus on the important Nagura stone. Stay tuned for muscled thews and busted bodices!

YMHOS

Links to Other Posts in the “Sharpening” Series

Sharpening Japanese Woodworking Tools Part 1

Sharpening Part 2 – The Journey

Sharpening Part 3 – Philosophy

Sharpening Part 4 – ‘Nando and the Sword Sharpener

Sharpening Part 5 – The Sharp Edge

Sharpening Part 6 – The Mystery of Steel

Sharpening Part 7 – The Alchemy of Hard Steel 鋼

Sharpening Part 8 – Soft Iron 地金

Sharpening Part 9 – Hard Steel & Soft Iron 鍛接

Sharpening Part 10 – The Ura 浦

Sharpening Part 11 – Supernatural Bevel Angles

Sharpening Part 12 – Skewampus Blades, Curved Cutting Edges, and Monkeyshines

Sharpening Part 13 – Nitty Gritty

Sharpening Part 14 – Natural Sharpening Stones

Sharpening Part 15 – The Most Important Stone

Sharpening Part 16 – Pixie Dust

Sharpening Part 17 – Gear

Sharpening Part 18 – The Nagura Stone

Sharpening Part 19 – Maintaining Sharpening Stones

Sharpening Part 20 – Flattening and Polishing the Ura

Please share your insights and comments with everyone in the comments section below. If you have questions or would like to learn more about our tools, please use the questions form located immediately below.

Sharpening Part 15 – The Most Important Stone

Orders are nobody can see the Great Oz! Not nobody, not nohow!

Gatekeeper, Emerald City

Many people high-center on the question: “What is the best way to sharpen my tools?”

I was hesitant to publish this series of posts about sharpening because, beginning with this post, I must answer this question by writing about tools and techniques that contradict many people’s sharpening religion. Some of those people will doubtless become emotional. As Benny Franklin once famously said: Ça ira, ça ira.

The objective of this post is to help our Beloved Customers properly maintain, sharpen and use the blades they purchase from us. Nothing else.

This post will not be a sharpening tutorial; that will be a future post.

We will examine the process of sharpening woodworking tools using mostly waterstones. We will touch on the motivations, goals and priorities related to sharpening you should consider, the minimum set of sharpening stones I recommend, and my suggestion for the most important stone in your arsenal, one you must be proficient in using.

Motivations

The Great and Powerful Oz has spoken!

You might have noticed from my previous posts that I like to understand motivations. Am I cynical? Perhaps, but where there are smoke and lights presented and money to be made, there is almost always someone behind the curtains spinning dials and pumping pedals. Oooh, pretty lights!

Anyone who does anything has a motive for doing it, and knowing that motive can help us evaluate the validity, and sometimes even the honesty, of what they do, say and write on a particular subject. How can we best ascertain the motivations of those advocating various sharpening methods and related accoutrements? Here are some simple questions you might want to ask: Are the promotions or promoters touting sharpening stones or other stuff they might profit from? Are they selling books on sharpening? Do they teach classes on sharpening? Do they have “sponsors” or “patrons” that supply them, at no cost or with large discounts, stones, diamond paste, sandpaper, sharpening machinery, and/or honing contraptions in exchange for promoting those goods? Are they “influencers” (yes, that’s a real vocation in the YouTube World) who are compensated for clicks? Do they publish reviews on products they receive for free? You see the pattern.

Regardless of their business model or motivations, many people give good advice. But some are shills, while some others are pretenders, and their advice will be colored accordingly. Caveat emptor, baby.

And then there is the most obvious motivation. After all, it doesn’t cost even $20 to make a Mechaultrasuperfine Ninja-purple Gold-dust-infused Musashi Walk-on-Waterstone that retails for $650. And have you calculated the long-term equivalent cost of diamond paste and abrasive films? Somebody’s making serious cash.

Just once I’d like to cross the road without having my motives questioned…

Whatever stones you select, I urge you to find a good balance of performance vs cost vs time vs sustainability, with sustainability referring to both the amount of landfill-stuffing the selected process creates as well as its long-term effect for good or ill on your blades. This 4-variable calculus depends not only on the characteristics of the stones and blades you use, but on your sharpening skills too, so it may take years to find the inflection points if you take a scientific approach. The quadratic formula does not yield useful results, sorry to say.

At one time or another I have tried and tested many popular sharpening “systems” including those that rely on jigs, machinery, sandpaper, plastic films, stick, liquid, paste, and powdered abrasives, buffers, strops and even superflat ceramic plates. I enjoy learning new things. They all get the job done, and all have serious merits, but to reduce the time and brain damage involved in this calculus, a wise man will learn from professionals, people who have been down the road before and actually use tools to feed their families, and who have no conflict of interest, be it stones, books, or clicks. That’s what I finally did, and I think it worked out well. But I need to issue a disclaimer before we go further.

Disclaimer

Here it is in red letters.

I say what I believe and believe what I say, even if it offends the “gurus” of sharpening. I buy their books and DVDs, watch their YouTube videos, and try the sharpening techniques and even the “tricks” they recommend, so I like to think I am not a “frog in a well,” as the Japanese saying goes. If I don’t know something, I will say so. I am not a child to be offended if you disagree with me, but I ask you to not become orcish.

Please note that we do not now and have never received goods, discounts, or financial compensation of any kind from anyone in exchange for modifying our opinion about sharpening tools and techniques.

I have personally taught many people how to sharpen tools over the years, but have never received a red cent for my time and haven’t used those training sessions as an excuse to sell stuff.

I have never done a product review.

I have never written a book or magazine article or even a blog post with advertiser support.

Please note that the document you are currently reading cost you nothing, was written and paid for by C&S Tools alone, and that there are no banners, commercials, or outside links on any of the pages in this blog. No SEO strategy at all. If Evil Google brought you here, it was not at our bidding.

We want to help our Beloved Customers, mostly professional woodworkers who already possess a certain level of skill, to level-up those skills. C&S Tools has no commercial incentive to mislead, and will not do so. But we do have a profit motive.

Remember, we have a 100% guarantee on the materials and workmanship of the tools we sell, so our sole financial motivation, and the very reason for this blog, is to help our Beloved Customers understand the tools we sell, and to become proficient in sharpening, maintaining, and using them so they won’t mistake a lack of skill and/or experience on their part as a problem with the tool. All most professionals really need is a little guidance. We want ecstatic customers because they become repeat customers. And we do hate to disappoint.

Goals, Objectives and Priorities

I mentioned 4 variable calculus above. Actually, it’s more like 5 variable calculus, the fifth variable being your goals and objectives for sharpening. Let’s examine those in more detail.

If satisfying curiosity are among your goals, then by all means try all the stones, sandpaper, films, pastes, jigs, contraptions, and machines available and methodically test them until they turn to dust. It simplifies the calculus, but the cost and time required to reach a final conclusion may become a heavy burden.

If beautiful blades, zen-like sharpening experiences, and improved hand-soul coordination are high among your ojectives (they’re included in mine), then you will want to try natural finishing stones. I heartily recommend them to those who have reached a certain level of skill with synthetic stones and are willing to roll the bones.

The performance of the sharpening system you select, including the following factors, is something should include in your calculations:

  • Time efficiency: How long does it take you to produce an adequately sharp edge starting from a dull/chipped one? How fiddly is the process? For this calculation you will need to determine how much your time is worth. Remember, while you may enjoy sharpening, from the professional’s viewpoint, time spent sharpening is non-productive time because, during the period you are working on tools, your hands, eyes, and mind cannot work on the stuff you contracted to deliver to the Customer;
  • Cost efficiency: How many billable hours and expensive supplies/tools/equipment must you expend to obtain an adequate cutting edge? For this calculation you will need to determine the cost of time, consumables (stones, sandpaper, film, paste, powder, beer) and equipment (grinders, jigs, plates, widgets, etc.) expended in producing an adequate cutting edge long-term. Even if you are not getting paid for your woodworking, your time still has value. And don’t forget to depreciate the cost of stuff. This is where synthetic waterstones shine in comparison to the many other sharpening systems out there.
  • Cutting efficiency: How well and how long does the sharpened blade cut? For this calculation, you need to determine what an “adequate cutting edge” is for you. For instance, given the same abrasives and expending the same amount of time to sharpen two blades, the blade with a rounded bevel, or even multiple bevels, is seldom as sharp as the blade with a simple flat bevel, as can be readily confirmed using a powerful loupe or microscope to examine the last few microns of the blade’s effective cutting edge (more on this subject in Part 21 of this series). Does the sharpening system you are testing tolerate or even promote bulging bevels or multiple bevels? Get out your loupe before your inner troll makes you say things you will regret.

If curiosity, pleasure and beauty are lower priority than practical performance in your list of objectives, then I suggest you focus on synthetic waterstones and the bedrock basics, at least for now:

  1. Obtain a minimum set of basic synthetic stones, or adapt what you already have;
  2. Learn how to use them skillfully;
  3. Practice those skills until they seep into your bones.

It is not an expensive process, but neither is it the instant short-term sort of thing the Gurus of Sharpening offer in their books and DVDs and classes through their tricks and gimmicks. It takes real skills that will serve you and your tools well for your entire life. And it all starts with the minimum set of stones.

The Goldilocks Set

Related image
Oh my goodness, just look at the time! I really must be going.

Sharpening stones are expensive consumables that disappear a little with every stroke. If you need more than 5 minutes to sharpen a plane or chisel blade that was not chipped or damaged, then you may be spending too long, and wasting your time and stones, so it’s important to determine the bare minimum set of stones that work best for you.

The Goldilocks set I recommend includes the following 4~5 stones/plates:

  1. A Rough Stone: 400~800 grit rough diamond plate or two carborundum stones;
  2. Medium Stones: Two 1,000 grit waterstones (I will get into the reasons for having two stones of the same grit in another post);
  3. A Finish Stone: 6,000~8,000 grit waterstone.

Please also note that I don’t take 10,000+ grit synthetic finishing stones or natural fine-finishing stones to jobsites. This decision is based on simple practical experience: Jobsites are rough and dirty places, and stones are fragile.

But there is an even more important reason: Airborne dust at jobsites will instantly degrade an expensive 10,000 grit rated stone to an effective 4,000 grit or less in an instant, making ultra-fine grit stones pointless. Dust will be the subject of the next post in this series.

The sharpening stones I normally use in the shop include a few beyond the minimum set described above. This set includes more stones, but the idea is that this finer gradation creates a better-quality cutting edge while consuming less of my expensive finishing stones. Natural stones can be pricey:

The packaging is fancier, but the content’s the same.
  1. One 400~800# diamond plate or two rough carborundum stones (only occasionally necessary);
  2. Two 1000# Imanishi waterstones (Bester brand) (usually necessary, but sometimes I skip it);
  3. Two 2000# Bester waterstones;
  4. One 6000# stone (fine enough for quickly finishing chisels and most planes);
  5. Two natural stones for finish planes and push chisels, or just for fun (a 10,000# synthetic stone works just as well).

Which Brand of Synthetic Stone?

I don’t think there is a dime’s worth of difference between the various synthetic stone manufacturers except for their marketing and distribution. I use what works for me and is available locally at the cheapest price. We don’t sell stones and have no relationship with or loyalty to any manufacturer.

Regardless of manufacturer, I do recommend you avoid the extra-thick variety of synthetic stone because the oven’s heat sometimes does not penetrate deep enough leaving the interior too soft.

The Most Important Stone

Everyone focuses like a laser on the finishing stone, the final stone in the process, but when sharpening a particular blade, the most important stone is really the first stone you use in the series, be it a 400 grit diamond plate or a 2,000 grit waterstone.

You may find this whole discussion passing strange, so I will explain. The roughest stone (or diamond plate, depending on the amount of steel that must be wasted and your available time and budget) you begin the sharpening process with builds the foundation of your cutting edge by performing the following two critical tasks:

  1. Removing damage at the cutting edge; and
  2. Shaping/flattening the cutting bevel.

Only a rough stone (400~800 grit) can accomplish the first task efficiently. If the truth of this statement is not self-evident, I won’t even try to convince you. Do the comparisons yourself: count strokes, time, and cost, measure angles, and peep at scratches through a high-power loupe.

In addition, your roughest stone or diamond plate is also the most efficient tool for shaping the bevel and cutting edge, if it needs to be adjusted. Until these two critical tasks are completed, none of the subsequent finer stones can accomplish anything efficiently, and the faster and more precisely these two tasks are accomplished the sooner one can stop sharpening and get back to the real job of woodworking.

The role of the finer stones in the sharpening sequence is simply to replace the deeper scratches left by the preceding rougher stone with progressively finer scratches. And since this work is done using more expensive, less-abrasive and slower-working stones, it is most cost/time-efficient to accomplish this task as quickly as possible. If you knock out the two foundational tasks listed above using your rough stone/plate well, then you can accomplish the subsequent polishing work at minimum cost and maximum speed. Screw it up and your blades will hate you.

Please be sure you understand the meaning of the previous 4 paragraphs. They are the heart of this article

So how does this work in real life? If the blade is chipped, dinged, or needs shaping, then I start repairing and reshaping the cutting edge’s foundation with my diamond plate. A carborundum stone, if very flat and kept flat, will work too. If my blade is only dull, but not damaged, and the bevel is in good shape, I start with a flat 1,000 grit stone. If the blade is starting to lose its edge, but is not damaged and still cuts, I start the process with a flat 2,000 grit stone. Notice the word “flat” is used a lot in this paragraph.

The objective, again, is to create an adequately sharp edge in the minimum amount of time and cost by starting the sharpening process with the cheapest, most aggressive stone appropriate to the blade’s condition for the heavy wasting and shaping thereby creating a bevel and cutting edge which you can then quickly polish to the final cutting edge using the more expensive, finer-grit stones. Wow, that’s a mouthful!

I want to make one thing perfectly clear before ending this post. Except for a few special situations, I don’t recommend using secondary bevels or micro-bevels except in special circumstances because, like training wheels on a bicycle, they are not an efficient long-term solution. In fact, they are a short-cut that has stunted many people’s sharpening skills. We will return to this subject later.

YMHOS

This image has an empty alt attribute; its file name is tenor.gif
The Marketing Department

Links to Other Posts in the “Sharpening” Series

Sharpening Japanese Woodworking Tools Part 1

Sharpening Part 2 – The Journey

Sharpening Part 3 – Philosophy

Sharpening Part 4 – ‘Nando and the Sword Sharpener

Sharpening Part 5 – The Sharp Edge

Sharpening Part 6 – The Mystery of Steel

Sharpening Part 7 – The Alchemy of Hard Steel 鋼

Sharpening Part 8 – Soft Iron 地金

Sharpening Part 9 – Hard Steel & Soft Iron 鍛接

Sharpening Part 10 – The Ura 浦

Sharpening Part 11 – Supernatural Bevel Angles

Sharpening Part 12 – Skewampus Blades, Curved Cutting Edges, and Monkeyshines

Sharpening Part 13 – Nitty Gritty

Sharpening Part 14 – Natural Sharpening Stones

Sharpening Part 15 – The Most Important Stone

Sharpening Part 16 – Pixie Dust

Sharpening Part 17 – Gear

Sharpening Part 18 – The Nagura Stone

Sharpening Part 19 – Maintaining Sharpening Stones

Sharpening Part 20 – Flattening and Polishing the Ura

Please share your insights and comments with everyone in the comments section below. If you have questions or would like to learn more about our tools, please use the questions form located immediately below.

Sharpening Part 13 – Nitty Gritty

“The true mystery of the world is the visible, not the invisible.”

Oscar Wilde

In this post we will dig into a few important nitty gritty points about sharpening stones everyone needs to know. Perhaps you already know all these points, but please ready your shovel because there may be at least one buried surprise.

A Flea’s-Eye View

When seen under high-magnification, the surface of a sharpening stone looks like millions of densely-packed stones embedded in a flat field. The smaller the stones, the finer the grit.

As the blade is pushed and pulled over these stones, they scratch and tear metal from the blade’s surface leaving behind scratches corresponding to the size of these small stones. This violence continues until the blade’s ura and bevel form a clean intersection of two planes.

A view of a blade sharpened with 1200 grit diamond plate showing the furrows left by individual pieces of grit

Seen under high-magnification, the cutting edge is jagged where these furrow-like scratches terminate at the cutting edge. To some degree, it may even look like a serrated sawblade. Some blades, like kitchen knives and swords, are used in a slicing motion to cut soft materials like meat and vegetables and enemy arms, and their performance benefits from a serrated cutting edge more than a highly-polished edge, and so do not need to be highly polished on fine-grit sharpening stones.

Plane and chisel blades, however, are used to cut wood, a material typically harder than foodstuffs, in a straight-on direction, not in a slicing motion, for the most part. In this situation, a rough, serrated cutting edge is weaker than a highly polished edge because the jagged edges are projecting out into space like the teeth of a handsaw blade, and are relatively unsupported and more easily damaged than a highly-polished blade with smaller, more uniform scratches terminating more cleanly at the cutting edge.

Therefore, in order to produce a sharp durable blade, we must make the microscopic cutting edge smoother and more uniform by using progressively finer grit stones to produce shallower and narrower scratches, and a thin, uniform cutting edge.

But how fine is fine enough? There is a curious phenomenon related to friction that is applicable to cutting edges, and is useful to understand.

The Friction Paradox

Imagine a cube of heavy stone with its downward flat face resting on the level, flat surface of a larger slab of similar stone. Let’s say it takes some specific measure of force pushing horizontally on the stone cube to overcome the static force of friction between the two stone surfaces in order to make the cube start moving.

If we gradually increase the degree of polish between the two contact surfaces and measure the force required to start the cube moving at each progressively higher level of polish, we will find the force decreases with each increment of increased polish, for a time. This is at least partially because the irregularities between the two surfaces (asperities) do not interlock as deeply when the surfaces become more polished.

However, at some point, more polishing brings the surfaces of the two stones into such intimate contact that the molecular attraction between them, and therefore the force necessary to move the cube, actually increases.

The Inflection Point

The same phenomenon occurs with tool blades. If you sharpen and polish your blades past a particular point, the friction and heat produced between blade and wood will increase, as will the energy that must be expended, while the resulting quality of the cut and durability of the cutting edge will not improve significantly. Of course, the time and money invested in stones spent sharpening past this point will be mostly wasted.

The inflection point where additional polishing yields increased friction with little improvement in cut quality will depend on your tool and the wood you are cutting, but you can gain a pretty good idea of where it is if you pay attention over time. While the sharpening stone manufacturers hate my saying it, in my well-informed opinion there is little practical gain, beyond self-satisfaction, to be had from sharpening chisels or planes past 6,000~8,000 grit, making this range of grit an inflection point in my mind. What about you?

Conclusion

I encourage you to conduct your own experiments to determine the inflection point in the case of your planes and wood you cut. Many who figure this out save themselves significant amounts of time and money sharpening over the long-term.

To those of our Gentle Readers that love sharpening more than woodworking, and enjoy putting money in the pockets of sharpening stone manufacturers more than keeping it for themselves, I apologize for pointing out the floater in the punch bowl. But you probably would have it noticed it eventually anyway, if only from the taste difference.

I will touch more on this important point in the next exciting installment in this scientificish adventure.

YMHOS

Links to Other Posts in the “Sharpening” Series

Sharpening Japanese Woodworking Tools Part 1

Sharpening Part 2 – The Journey

Sharpening Part 3 – Philosophy

Sharpening Part 4 – ‘Nando and the Sword Sharpener

Sharpening Part 5 – The Sharp Edge

Sharpening Part 6 – The Mystery of Steel

Sharpening Part 7 – The Alchemy of Hard Steel 鋼

Sharpening Part 8 – Soft Iron 地金

Sharpening Part 9 – Hard Steel & Soft Iron 鍛接

Sharpening Part 10 – The Ura 浦

Sharpening Part 11 – Supernatural Bevel Angles

Sharpening Part 12 – Skewampus Blades, Curved Cutting Edges, and Monkeyshines

Sharpening Part 13 – Nitty Gritty

Sharpening Part 14 – Natural Sharpening Stones

Sharpening Part 15 – The Most Important Stone

Sharpening Part 16 – Pixie Dust

Sharpening Part 17 – Gear

Sharpening Part 18 – The Nagura Stone

Sharpening Part 19 – Maintaining Sharpening Stones

Sharpening Part 20 – Flattening and Polishing the Ura

Please share your insights and comments with everyone in the comments section below. If you have questions or would like to learn more about our tools, please use the questions form below.

Sharpening Part 12 – Skewampus Blades, Curved Cutting Edges, and Monkeyshines

Even monkeys fall from trees (猿も木から落ちる)

Japanese saying
A famous wood carving of 3 monkeys located at Nikko Toshogu Shrine post resconstruction that illustrates a famous saying originating in China that also works as a pun in the Japanese language. From right to left: See no evil; Speak no evil; Hear no evil (見ざる、聞かざる、言わざる).

Ideally, a tool blade will have absolutely uniform dimensions: the right thickness and taper, perfect cross-sections, uniform curvature, and straight edges and surfaces. However, professional grade Japanese tools are not made on CNC machines, but are hand forged, and have dimensional imperfections. Indeed, imperfections are part and parcel of all human endeavors. Most imperfections don’t matter; Sometimes they make the tool better; Other times they need to be remedied.

You, Gentle Reader, may not notice that the blade or cutting edge of one of your chisels or planes is “skewampus,” and consequently the cutting results are less than ideal. You may blame those poor results on your technique in using the tool or the irregular wood grain, when the real problem is the shape of the blade’s cross-section, or your unintentionally sharpening the blade with a skew. We will examine this problem in this post.

We will also look at the curved or “cambered” cutting edge profile in plane blades, the benefits and undesirable results it can produce, and how to incorporate this blade profile intelligently into your woodworking repertoire.

Many people, like monkeys in trees, learn bad habits from their friends and teachers. We hope this post will help you understand what is going on with your woodworking blades, and how to shape and sharpen them intelligently instead of just monkeying around. Please be sure to BYOB (bring your own bananas).

A serious craftsman doing Fine Woodworking in a Pixie-free workshop (notice the strategically-placed boots).

Dealing With Skewampus Blades

Skewampus is an interesting word I learned from my mother. I am told it is a combination of the word “Cattywampus” meaning “in disarray,” and “askew.” I think it is the perfect word for describing the ailments some blades suffer.

While less than ideal, it is not unusual for the thickness of a chisel blade’s cross section to vary slightly across its width, with one side being thicker than the other, forming an irregular quadrilateral cross section. This irregularity is found in plane blades too, but it is not typically a problem. Since there is more steel on the thicker side, the cutting edge will tend to develop a skew during sharpening.

Japanese plane and chisel blades are formed by laminating a layer of hard steel to a much softer body made of extremely low-carbon steel or iron. If the lamination exposed at the cutting edge is not uniform, the area of the blade with more hard steel touching the sharpening stone will abrade slower than areas with less exposed hard steel such that the cutting edge will tend to become skewed during sharpening. Perfection is not required, but the uniformity of the lamination is an important detail to observe when purchasing Japanese tools.

Likewise, Western plane and chisel blades that are not uniformly heat-treated, and that exhibit differential hardening across the bevel’s width, will also tend to become skewed during sharpening as one side of the bevel abrades quicker than the other. This problem is more common than you might imagine, especially in the case of inexpensive tools where appearance and low price are given higher priority than quality.

Anyone that has experience bidding high-dollar construction projects will understand the statement “the most profitable job may be the one you lose.” Cheap tools are much the same way: that low-cost chisel or plane may look good on paper, but if you count your time worth anything, if you dislike headaches, and real-world performance matters to your bottom line, then such a tool is often disastrous. Caveat emptor, baby.

A chisel or plane blade that has an irregular cross section or a skewed cutting edge may not be a problem for many cutting operations. However, when cutting mortises, a chisel blade with a skewed cutting edge or irregular cross section will tend to drift to the side gouging the mortise’s walls and ruining tolerances. If you find that your mortise walls are gouged, or that tolerances are poor, check your chisel blade’s shape, and correct any deformities.

Like all human work spaces, Japan’s smithies are not immune from pixie infestation despite annual blessings by Shinto priests and periodic offerings of rice, salt and wine to the spirits. In a previous post we discussed supernatural predators, so I will refer you to it for antidotes to pernicious pixie pox. But the deformities we are examining in this post are more often the natural result of the human eye misjudging hammer blows or non-judicious use of grinder wheels rather than precocious pixies at play.

If your blade’s deformity is not excessive, you can compensate by applying a little extra pressure on the blade’s thicker side while sharpening it.

It is interesting how a little off-center pressure on a blade being sharpened over many strokes can change its shape. Many people unintentionally deform their cutting edges by not paying attention to the amount and location of the pressure their fingers apply. A word to the wise.

Another potential solution is to skew the blade in relation to the direction of travel when sharpening the bevel. This works because the leading corner of a skewed blade is abraded quicker than the trailing corner. But once again, inattention causes many people to skew their blades when moving them around on their sharpening stones unintentionally creating, instead of intentionally correcting, skewed cutting edges. There is nothing wrong with skewing the blade when sharpening so long as you are aware of the distortion this practice can produce and compensate accordingly. Another word to the wise.

If these methods don’t compensate adequately, you may want to grind and lap a chisel blade to a more uniform cross-sectional shape. A chemical bluing solution used afterwards will help conceal the shiny metal exposed by this operation if your chisel objects to the shiny spots. Some of them can be quite vain, you know.

A chisel with a an adequately uniform lamination and cross-section, and nice polish.

Cutting Edge Profiles

Many people have access to electrical jointers and planers, but relatively few have industrial equipment with the capacity to dimension wide boards such as tabletops. And of course architectural beams and columns are typically too long or too heavy to dimension with most stationary electrical equipment.

The choices available to most people for dimensioning such materials therefore are either handheld electrical power planers and/or sanders, or axes, adzes and hand planes. Powerplaners, sanders, axes and adzes are beyond the scope of this article, but we will look at hand planes.

I need more than one plane? You can’t be serious!

Although the very idea gives some woodworkers vapors (I don’t mean gas), an efficient craftsman will have multiple planes with cutting edges honed to profiles matched to specific operations.

Everyone that dimensions larger pieces of lumber by hand needs a plane with a wide mouth and a curved or “cambered,” cutting edge called a “scrub plane” in the West, and “arashiko kanna” in Japan.

This variety of plane excels at hogging a lot of wood quickly when the craftsman needs to significantly reduce the thickness of his lumber.  If the blade is narrow and curvature is deep, this plane will hog wood quickly, but leave a deeply rippled surface, often with bad tearout.

One might also have a second arashiko, or jack plane with a wider blade with a shallower curvature for the next steps in the dimensioning process. Such a plane will not hog wood as quickly, but it will produce a surface that is closer to flat and smooth and with less tearout. You can see the advantage of having two arashiko planes, or a scrub plane and a jack plane, with different cutting edge profiles when dimensioning lumber.

Many Gentle Readers use electrical-powered planes to dimension lumber before turning it into furniture, doors, chairs, or sawdust, etc. and are aware that planers always leave tiny ripple-like scallop cuts on the wood’s surface, along with some tearout. This will not do as a final surface. A hand-plane finish is far superior, but it doesn’t make sense to remove any more than the bare minimum of wood necessary to remove the washboard.

A finish plane is the perfect tool for this job on condition that it is sharp, set to a fine cut, the chipbreaker is tuned and set properly, the blade profile is appropriate for the width of the wood to be finished, and the wood does not have too many large knots. In one or two passes such a plane can easily remove the ripples and leave the wood clean and shiny without changing its dimensions much at all.

Assuming the wood is cooperative and one knows how to sharpen and setup their plane properly, blade profile frequently remains a key factor many fail to grasp. Obviously, the curved cutting edge of a scrub plane cannot produce the perfectly flat surfaces required for joining two pieces of wood together. On the other hand, the corners of a perfectly straight blade will leave clearly visible steps or unsightly tracks on the surface of a board wider than the blade, which is not a problem when rough dimensioning a board, but is painful to see if the board’s surface is to be left with just a planed finish.

So how do we solve this conundrum? When finish planing, the professional approach is to use two planes each with a different cutting edge profile. The first type of finish plane has a perfectly straight cutting edge used to plane pieces narrower than the blade’s width. Since the blade’s corners are not riding on the wood while cutting it, they won’t leave tracks and ridges.

The second type of finish plane found in the professional’s toolkit has a curved cutting edge, or more correctly, curved just at the corners to prevent it from leaving tracks and ridges when planing boards wider than the blade. Nearly all the edge is left straight, but creating this tiny amount of curvature at the right and left corners causes it to smoothly disappear into the plane’s mouth so no tracks are made and any ridges are nearly impossible to see or feel. In other words, the corners of the cutting edge never touch the surface of the board, and so don’t leave discernible tracks or ridges. The finer the cut made the smaller any ridges created will be. Indeed, where a high-quality surface is required, the final cut with the finish plane will produce shavings thin enough to see one’s fingerprints through.

You may want to reread the previous two paragraphs to make sure you understand what these two cutting edge profiles are and what they can accomplish before you read further.

Naturally, a professional doing high-quality work needs at least two finish planes, one with a straight cutting edge used to produce flat, precisely-dimensioned surfaces on wood narrower than the blade’s width, and another finish plane with a cutting edge very slightly curved at the corners used to finish wider surfaces.

There are those that advocate using a curved blade, sometimes dramatically “cambered” as some call them, for all applications. Those who teach this sloppy technique twist themselves into knots justifying tricks to approximate flat surfaces using such blades. I have no doubt this is an ancient technique, but I think it is a sad practice that sprung from the carelessness of some craftsmen in flattening their sharpening stones, and with time this bad habit became a tradition in some quarters. I strongly suspect fans of this strange way of doing business habitually sand all visible surfaces anyway so tracks and ridges are not a problem for them. But the fact remains that perfectly flat, track/ridge-free surfaces work best for joinery.

Tradition and “monkey see monkey do” are a useful place to start, but as his skill level increases, the thoughtful and efficient craftsman will eventually seek to confirm the validity of the traditions he has been taught. I urge you to get started early.

Sadly, too many people never notice the strange instruction label pasted to their boot’s sole, nor that smelly stuff sloshing around inside.(ツ)

monkey-see-monkey-do
Mommy monkey teaching baby monkey bad habits. When will they ever learn?

Conclusion

As we come to the end of this post, my advice to you, Gentle Reader, is to learn two bedrock basic skills to perfection. First, learn how to keep your sharpening stones flat; And second, learn how to sharpen your blades to have a straight cutting edge. Everything else will flow naturally from these skills. Your blades deserve it. We will talk more about these subjects in the future.

In this post, we have discussed 12 serious points about plane and chisel blades and how to use and improve them all but a few woodworkers in the West are unaware of, or ignore, but which are common knowledge among professional Japanese woodworkers in advanced trades. While condensed, it is enough information to fill a book, but we are giving it to you for the price of bananas (BYOB, remember?). We hope you picked up on each point, and test those that are new to you.

The next installment in this simian soap opera of sharpening will focus less on monkeyshines, and more on stones and techniques. Please stay tuned.

YMHOS

I can’t wait to read the next post!!

Links to Other Posts in the “Sharpening” Series

Sharpening Japanese Woodworking Tools Part 1

Sharpening Part 2 – The Journey

Sharpening Part 3 – Philosophy

Sharpening Part 4 – ‘Nando and the Sword Sharpener

Sharpening Part 5 – The Sharp Edge

Sharpening Part 6 – The Mystery of Steel

Sharpening Part 7 – The Alchemy of Hard Steel 鋼

Sharpening Part 8 – Soft Iron 地金

Sharpening Part 9 – Hard Steel & Soft Iron 鍛接

Sharpening Part 10 – The Ura 浦

Sharpening Part 11 – Supernatural Bevel Angles

Sharpening Part 12 – Skewampus Blades, Curved Cutting Edges, and Monkeyshines

Sharpening Part 13 – Nitty Gritty

Sharpening Part 14 – Natural Sharpening Stones

Sharpening Part 15 – The Most Important Stone

Sharpening Part 16 – Pixie Dust

Sharpening Part 17 – Gear

Sharpening Part 18 – The Nagura Stone

Sharpening Part 19 – Maintaining Sharpening Stones

Sharpening Part 20 – Flattening and Polishing the Ura

Please share your insights and comments with everyone in the comments section below. If you have questions or would like to learn more about our tools, please use the questions form located immediately below.

Sharpening Part 11 – Supernatural Bevel Angles

This image has an empty alt attribute; its file name is John_Bauer_-_The_Princess_and_the_Trolls_-_Google_Art_Project.jpg

Pixie, kobold, elf, and sprite, All are on their rounds tonight; In the wan moon’s silver ray, Thrives their helter-skelter play.

Joel Benton

Iron Pixies

Gentle Reader, have you ever placed a tool down, only to later discover it has vanished into thin air? Do your tools ever become unexplainably dull or corroded within what seems like just a few days after cleaning and sharpening them? If so, you may have an Iron Pixie infestation without realizing it.

Respected fairyologists theorize that, unlike their timid brethren frolicking in forests, or their blingy cousins in Hollywood, New York, and Washington DC who delight in tricking the mass media, film industry and corrupt politicians into constantly making greedy, immoral, hypocritical fools of themselves, Iron Pixies (genus Fatum Ferrum), do not fear iron or iron alloys. Indeed, besides pilfering and concealing tools that contain iron, they love nothing more than to use their corrosive powers to return this metal to its natural state through the thermodynamic chemical process known as “rubeum, et conversus abibo” (turn red and go away).

These piratical pixies become especially joyful if the owner of the snatched tool is unable to find it after much frantic searching, and is eventually forced to buy a replacement. Only when they see the replacement tool will the pernicious pixies permit the owner to locate the pilfered tool, usually rusty and chipped.

We’ll come back to the supernatural aspects of woodworking tools, but first let’s examine some more mundane details about sharpening blades, and a few things that typically go wrong with them.

The Ideal Bevel Angle

There is such a thing as an “ideal bevel angle” for each blade in each cutting situation, one that cuts the wood quickly, cleanly, with minimum force expenditure and that keeps the blade effectively sharp for the maximum amount of cutting possible, but determining this angle is not an easy calculation since it is difficult and expensive to actually observe what is happening at the cutting edge from a shaving’s-eye-view.

For example, a steep  60° bevel angle on a chisel will support the cutting edge thoroughly and will be durable, but it will pound the wood more than cut it wasting time and energy and damaging the wood unnecessarily. On the other hand, a 15° angle will cut well, but is likely to chip and dull quickly. A balance is necessary.

This balance will depend on many factors including hardness and abrasiveness of the wood you are cutting at any time (e.g. Sugar Pine versus Ipe), the quality and nature of your chisel blade, the type of cut you are making (low-pressure surface paring versus high-pressure deep mortises), and the care you take to protect the cutting edge. Yes, technique matters.

Determining the ideal bevel angle is ultimately a trial and error process the diligent craftsman will unconsciously perform until it is second nature, but the following are some general guidelines to get you started.

Most Japanese woodworking tools, including plane blades and striking chisels (oirenomi, atsunomi, tatakinomi, mukomachinomi) perform well in most construction and furniture woods with the standard 27.5°~30° bevel angle. This is a good compromise, acute enough to cut most wood efficiently without too much friction, while still providing adequate support to the thin cutting edge to avoid chipping.

But like any rule, there are exceptions. For example, 35° is often a superior bevel angle for chisels when quickly cutting mortises in harder woods or planes shaving tropical hardwoods.

When cutting very soft woods, such as Paulownia, similar to balsa wood, a 22~24° bevel angle may work best.

Paring chisels (tsukinomi), when used properly, are subject to less violent forces than striking chisels, and can handle a 24° bevel angle. But for most woods, a professional-grade Japanese plane or chisel blade will likely experience chipping if the angle is much less.

There are many variables and potential solutions one might consider, but as a general rule, I recommend starting your experiment with a 27.5~30° bevel angle for plane and chisel blades.

If you find that your blade chips or dulls quicker than you think it should, increase the angle gradually until it calms down. This can result in a double-bevel blade, one difficult to sharpen freehand. In this case, I fully support using a honing jig, at least until you achieve a flat bevel wide enough and stable enough to sharpen freehand. But don’t handicap yourself by relying solely on honing jigs because they can become like training wheels on a bicycle: slow and childish.

Mercurial Bevel Migration

There is a strange, almost supernatural phenomenon many woodworkers experience, the first evidence of which is a plane or chisel blade that previously held a sharp edge a long time suddenly and unexplainably beginning to dull or roll or chip sooner than before. Even professionals with many years of experience occasionally see their tools exhibit this nasty behavior.

Some craftsmen faced with this dilemma begin to question their sanity. They may ask themselves: “Has heaven turned its face against me? How do I rid myself of this curse? Do I need to see a shrink?” Other craftsmen, more aware of the dangers of pernicious pixies, draw strange hex symbols on their walls or inlay brass circles and pentagrams into their floors to exorcise them from their workshop. Indeed, this practice has a long history in Europe and America.

Related image

Unfortunately, more than one blacksmith has been falsely accused of poor workmanship when the fault actually lay with the tool’s owner unwittingly allowing Iron Pixies to run amok. If this happens to your tools, please use the methods described below to purge any pestilent pixies in the area.

You would be wise to consider all possible causes of Mercurial Bevel Migration (MBM), including those unrelated to any infernal fiends that may or may not be skulking in your lumber stacks.

But if not pesky pixies, what else could cause this maniacal metallurgical malfeasance?  Never fear, Gentle Reader, there is another possible explanation, one that can be resolved without paying for years of expensive psychotherapy and mind-altering drugs, or placing small bowls of blood and milk around your workshop, or enduring the pain of tattoo needles, or paying for stinky ceremonies involving burning sage and spirit drums.

The more likely cause is simply that it’s human nature when sharpening chisels and Japanese blades with their laminated, top-heavy construction to apply more pressure to the bevel’s rearward half (farthest from the cutting edge) abrading the softer jigane body more than the harder hagane cutting layer. Eventually, as the soft jigane wears away, the bevel angle will decrease to the point where the cutting edge will lose support and become fragile.

Once you are aware of this tendency and take preventative measures (and assuming you don’t have an iron pixie infestation), all should be well.

Next let’s examine some measures to get rid of both this bad habit and trixy pixies.

Pixie Predation Prevention & Pacification

If you suspect the presence of iron pixies, you should perform a Pixie Detection test. A reliable method is described in the next section below.

In any case, to avoid pixie infestation, you should create a workshop environment unfriendly to pixies. The following is an partial list of measures I have found to be effective.

Image result for brass bench dog
Brass bench dogs are an effective pixie repellent
  1. Cleanliness: Clean bench surfaces and sweep the floors daily. Periodically vacuum and wet-mop workshop floors twice a year during the winter and summer solstices (approximately June 21 and December 21);
  2. Add more lighting: Iron Pixies fear light because it reveals them to their enemies;
  3. Keep a pair of boots near the door into the workshop: Pixies are deathly afraid of boots, especially when they contain the feet of sharp-eyed human children, but just the sight of boots will prevent them from entering a space;
  4. Keep brass benchdogs in your workshop. Expert fairyologists insist, and I agree, that having a brass bench dog (remember, Iron Pixies do not fear iron or steel or the IRS) or two close by will banish Iron Pixies to the workshop’s dark recesses and keep their nasty claws away from tools. The deterrent effect of bench cats is unclear, but if you decide to rely on one, be sure it bothers to stay awake;
  5. Welcome spiders: Although this may seem to contradict No. 1 above, Iron Pixies fear spiders, especially daddy longlegs, who tangle them in their webs.
  6. Make regular offerings to the gods of handsaws. More on this subject in future posts.
Richard Kell bevel gauge
A compact and effective brass bevel angle gauge by Richard Kell

A more mundane but sure way to prevent MBM is to make or buy a bevel angle gauge and regularly use it to check your bevels during sharpening. Aluminum, stainless steel or even plastic gauges will work of course, but brass or bronze are more effectual at purging perfidious predatory pixies because copper is toxic and zinc causes pixies indigestion. Be sure to store it close to your valuable steel tools to help repel the maniacal monsters.

Here’s the important thing: once you have this tool on hand, use it to check each blade before, during and after sharpening to ensure you are maintaining the correct bevel angle instead of allowing it to decrease incrementally over repeated sharpening sessions. Make this a firm habit. More on this important subject in future posts.

Remember to measure the bevel angle at the blade’s far right or left edges because the hollow-ground ura of Japanese blades makes it difficult to correctly measure the angle if you check it elsewhere.

Pixie Detection Methods

A serious pixie infestation in a toolchest located in a clothing-optional workshop. Notice the absence of bench dogs, bevel angle gauges and boots in this image.

Iron Pixies are secretive creatures most people never see, but if you suspect you have an infestation, a detection test is called for.

While there are many proven methods to test for pixie infestation, the least expensive non-toxic iron pixie detection test is to sharpen a plane blade, and while doing so, attempt to “stick it” on the stone as in the photo below. This phenomenon is evidence the stone and the blade are in such perfect contact that the suction between the blade, water and mud on the stone’s surface strong is enough to support the weight of the blade.

No, this is not a trick photo with concealed supports, superglue, or photoshop enhancements. The blade is “stuck” to the wet stone’s surface. This is a rite of passage those who wish to become proficient in sharpening must accomplish, iron pixies or no. Not recommended for potato chip-thin Bailey-style plane blades.

If you are unable to accomplish this marvelous feat even after many attempts, you can be assured of the presence of peevish pixies nearby. In that case, use the preventative measures listed in the section above. You should also flatten your sharpening stones (especially the rough and medium grit stones) and make sure your blade’s bevel is perfectly flat. Bulging bevels are the pernicious pixie’s playground. (Aha! Iambic pentameter!)

Fair warning: If you stubbornly persist in your efforts to stick a plane blade before purging the area of pixies, they may go berserk to prevent this sublime event from occurring. If that happens, Katy bar the door!

Infernal Pixies! You Shall Not Pass!!

In the next stage of our adventure, we will examine some of the health ailments blades commonly suffer.  High cholesterol in chisels? Planes with pneumonia? Or just toolish hypochondria? Stay tuned to find out more.

YMHOS

Links to Other Posts in the “Sharpening” Series

Sharpening Japanese Woodworking Tools Part 1

Sharpening Part 2 – The Journey

Sharpening Part 3 – Philosophy

Sharpening Part 4 – ‘Nando and the Sword Sharpener

Sharpening Part 5 – The Sharp Edge

Sharpening Part 6 – The Mystery of Steel

Sharpening Part 7 – The Alchemy of Hard Steel 鋼

Sharpening Part 8 – Soft Iron 地金

Sharpening Part 9 – Hard Steel & Soft Iron 鍛接

Sharpening Part 10 – The Ura 浦

Sharpening Part 11 – Supernatural Bevel Angles

Sharpening Part 12 – Skewampus Blades, Curved Cutting Edges, and Monkeyshines

Sharpening Part 13 – Nitty Gritty

Sharpening Part 14 – Natural Sharpening Stones

Sharpening Part 15 – The Most Important Stone

Sharpening Part 16 – Pixie Dust

Sharpening Part 17 – Gear

Sharpening Part 18 – The Nagura Stone

Sharpening Part 19 – Maintaining Sharpening Stones

Sharpening Part 20 – Flattening and Polishing the Ura

Please share your insights and comments with everyone in the comments section below. If you have questions or would like to learn more about our tools, please use the questions form located directly below.

Sharpening Part 10 – The Ura 浦

If a craftsman wants to do good work, he must first sharpen his tools.

Confucius, The Analects
Related image
Geographic Ura
Chisel Ura

We talked about the Ura previously in post No. 9. It is a defining detail in most Japanese woodworking blades, and one we must understand if we are to efficiently sharpen them. In his post we will look into this important feature in more detail.

What is the Ura?

Japanese plane and chisel blades have a unique and intelligent design feature at what is called the “flat” on Western plane and chisel blades, called the “Ura” (pronounced oo-rah).

Ura translates into the English language as “bay,” as in a protected area where the sea meets the shore. At the center of the ura is a hollow-ground, depressed area in the hard steel hagane layer that serves two purposes.

One purpose is to make it easier to keep the blade’s “flat” (the shiny areas surrounding the depression) planar (in the same plane).

If you pay attention when sharpening your wide Western chisels and planes you will notice that, after many sharpening sessions, the blade’s flat, which was once planar, becomes convex with a high point at the flat’s center making it difficult to keep the extreme cutting edge, especially the corners of the blade, in close contact with the sharpening stone. Yikes!

This doesn’t occur because you don’t know how to sharpen your blades, but simply because your sharpening stones/platens/paper tend to abrade the blade’s perimeter more aggressively than the center. The resulting curvature makes it more difficult to polish the flat’s extreme cutting edge. Major buzzkill.

Because of the Ura, Japanese woodworking blades are quickly fettled initially and tend to stay planar without a second thought for many years of hard use, an important benefit if you count your time worth anything.

Another purpose of the Ura is to reduce the square inches or square millimeters of hard steel you must polish during each sharpening session. As you can see from the photo above, the shiny perimeter land is all that touches the sharpening stone. Compare this with the black area which doesn’t touch the stone. That’s a lot of hard steel you don’t have to deal with. Besides making the job easier, it also saves a lot of time when sharpening and helps one’s expensive sharpening stones last longer. Time is money and stones ain’t cheap, as my old foreman used to say. Even if you don’t use your tools to make a living, remember that time spent sharpening is time stolen from the pleasure of making wooden objects.

The Downside Of the Ura

The Ura detail is not all meadow flowers and fairy farts, however, because it does have one unavoidable downside: Over many sharpening sessions the Ura unavoidably becomes gradually shallower, and the lands surrounding the Ura on four sides become correspondingly wider. It is not uncommon to see old chisels and plane blades with the depressed area of the Ura almost gone. You can postpone this day by sharpening the Ura wisely. However, in the worst case where the Ura disappears entirely, you will still be left with an entirely usable Western-style flat, so not all is lost.

In the case of plane blades, unless the plane’s ura is subjected to a brutal sharpening regime, the land that forms the cutting edge (called the “Ito ura” meaning “strand” as in a flat area on a riverside, in Japanese) tends to gradually become narrower, and even disappear entirely after numerous sharpenings. Of course, when this happens, the blade loses its cutting edge, and the land must be restored by “tapping out” or bending the cutting edge towards the ura side, and then grinding it flat to form a new ito-ura land. Tapping out a blade requires some caution, but is not difficult. I will not deal with this aspect of blade maintenance in this post.

In the case of chisels, which have smaller and shallower ura compared to wider plane blades, the land at the cutting edge does not typically require tapping out, although it’s certainly possible to tap out wider chisel blades. Narrow chisel blades, on the other hand, are difficult to tap out without damaging them due to the rigidity produced by the hard steel layer (detailed in the previous post in this series) wrapped up the blade’s sides.

Mitsuura Chisels

Ichimatsu Nomi Ura (by Kiyotada)
Spearpoint Mitsuura chisels by Sukemaru using EDM technology. Sadly, Mr. Usui no longer produces them.

Some chisels are made with multiple ura, typically called “mitsuura” meaning “triple ura.” Mitsuura chisels are more difficult to sharpen because the area of hardened steel that must be polished is larger. The Ura of mitsuura chisels also tend to wear-out quicker than single-ura chisels because each individual ura is shallower in depth than standard Ura. I am not a fan of multiple ura except in a few specific applications.

In the next stage of our journey into the mysteries of sharpening, we will wander through the metaphysical realms of the “Fae.” Be sure to have a brass bench dog in your pocket when we leave the well-lighted pathways.

YMHOS

Links to Other Posts in the “Sharpening” Series

Sharpening Japanese Woodworking Tools Part 1

Sharpening Part 2 – The Journey

Sharpening Part 3 – Philosophy

Sharpening Part 4 – ‘Nando and the Sword Sharpener

Sharpening Part 5 – The Sharp Edge

Sharpening Part 6 – The Mystery of Steel

Sharpening Part 7 – The Alchemy of Hard Steel 鋼

Sharpening Part 8 – Soft Iron 地金

Sharpening Part 9 – Hard Steel & Soft Iron 鍛接

Sharpening Part 10 – The Ura 浦

Sharpening Part 11 – Supernatural Bevel Angles

Sharpening Part 12 – Skewampus Blades, Curved Cutting Edges, and Monkeyshines

Sharpening Part 13 – Nitty Gritty

Sharpening Part 14 – Natural Sharpening Stones

Sharpening Part 15 – The Most Important Stone

Sharpening Part 16 – Pixie Dust

Sharpening Part 17 – Gear

Sharpening Part 18 – The Nagura Stone

Sharpening Part 19 – Maintaining Sharpening Stones

Sharpening Part 20 – Flattening and Polishing the Ura

Please share your insights and comments with everyone in the comments section below. If you have questions or would like to learn more about our tools, please use the questions form located immediately below.
